Vanilla Sky Square
Vanilla Sky Square ceiling series features molded white glass diffuser in 14" (36cm), 18" (46cm) or 24” (61cm) diameter sizes. Also available in round versions. Halogen T3 double ended lamp, energy efficient Krypton/Xenon T4 lamp or two 3000K T4 compact fluorescent lamps and ballast included. General light distribution.
Diffuser:
White
Lamp:
Halogen (H)
14H1 - T3LONG/RSC/150W
Krypton/Xenon (K)
18K1 - KX180T4CL/180W
24K1 - KX180T4CL/180W
Fluorescent (F)
14F1 - 2xT4/2G7/9W
18F1 - 2xT4/G24D-3/26W
24F1 - 2xT4/G24D-3/26W
Total Wattage:
14H1 - 100W
18K1 - 180 = 250W
24K1 - 180 = 250W
14F1 - 18W-3000K
18F1 - 52W-3000K
24F1 - 52W-3000K
Dimmer:
Halogen - incandescent
Krypton/Xenon - incandescent
Fluorescent - electronic ballast; not dimmable
Dimensions:
14 - L 14" x W 14" x H 4"
L 36cm x W 36cm x H 10cm
18 - L 18" x W 18" x H 4"
L 46cm x W 46cm x H 10cm
24 - L 24" x W 24" x H 4"
L 61cm x W 61cm x H 10cm
Weight:
14 - 6 lbs (3kg)
18 - 8 lbs (4kg)
24 - 13 lbs (6kg)
Ordering Code
| Ordering Code | Description | Size | Lamp | Voltage | ||||
| VSKY | - | SQ | - | 18 | - | H1 | - | Standard 120V (leave blank) |
| - SQ Square |
- 14" (36cm) - 18" (46cm) - 24" (61cm) |
- H1 Halogen - K1 Krypton/Xenon - F1 Fluorescent |
- 2 230V 50Hz - 3 277V 60Hz (F1 only) |
