Satin Ceiling
Satin Ceiling series features white frosted glass and a satin nickel finish. Available in 7" (18cm), 12" (30cm), 15" (38cm) and 18" (46cm) diameter versions. T3 double ended halogen or T5 Circline fluorescent lamps and electronic ballast included. 7" (18cm) diameter available in halogen only. 15" (38cm) and 18" (46cm) versions also available with fluorescent emergency lamps (F1E) in 120V. Halogen (H1) and fluorescent (F1) available in 120V, 230V (50Hz); fluorescent (F1) also available in 277V (60Hz). General light distribution.
Diffuser:
White
Body Finish:
Satin Nickel
Lamp:
Halogen (H)
7H1 - T3short/RSC/75W
12H1 - T3short/RSC/200W
15H1 - T3long/RSC/250W
18H1 - T3long/RSC/300W
Fluorescent (F)
12F1 - T5circline/2GX13/22W
15F1/F1E - T5circline/2GX13/40W + 22W
18F1/F1E - T5circline/2GX13/40W + 22W
Total Wattage:
7H1 - 75W
12H1 - 200W
15H1 - 250W
18H1 - 300W
12F1 - 22W-3500K
15F1/F1E - 62W-3500K
18F1/F1E - 62W-3500K
Dimmer:
Halogen - incandescent
Fluorescent - electronic ballast; not dimmable
Dimensions:
7 - L 7" x W 7" x H 2.5"
L 18cm x W 18cm x H 6cm
12 - L 12" W 12" x 3.75"
L 30cm x W 30cm x H 9.5cm
15 - L15" x W 15" x H 4"
L 38cm x W 38cm x H 10cm
18 - L 18" x W 18" x H 4.5"
L 46cm x W 46cm x H 11.5cm
Weight:
7 - 5 lbs (2 kg)
12 - 8 lbs (4 kg)
15 - 10 lbs (4.5 kg)
18 - 11 lbs (5 kg)
Ordering Code
| Ordering Code | Size | Lamp | Finish | Voltage | ||||
| SATIN | - | 7 | - | H1 | - | SN | - | Standard 120V (leave blank) |
|
- 7" (18cm) - 12" (30cm) - 15" (38cm) - 18" (46cm) |
- H1 Halogen - F1 Fluorescent (7" not available in fluorescent) |
- SN Satin Nickel |
- 2 230V 50Hz - 3 277V 60Hz (F1 only) |
